HDI blind buried via PCB

High-Performance HDI Pcbs for New Energy Vehicle Control Board Smartphones and Tablets Consumer Electronics Precision SMD PCB Manufacturing and Assembly Services
Description Our ServiceFAQ
Description

Model NO.

HDI PCB

Structure

Double-Sided Rigid PCB

Dielectric

FR-4

Material

Polyester Glass Fiber Mat Laminate

Application

Aerospace

Flame Retardant Properties

V0

Processing Technology

Electrolytic Foil

Production Process

Semi-Additive Process

Base Material

Copper

Insulation Materials

Organic Resin

Brand

Customers Brand

Certification

IATF16949, UL, ISO

MOQ

No

Surface Treatment

Gold Finger/Hard Gold

Test

100% E-Test

Copper Thickness

0.5-12oz(18-420um)

Hole Diameter

Min0.05mm

Min. Line Spacing

0.10mm(4mil)

One Stop Service

PCB Assembly, Component Sourcing, Box Building

Board Thickness

0.2-6mm

Solder Mask Color

Green/Black/White/Red/Blue/Yellow

Min. Line Width

0.10mm(4mil)

Max. Finished Board Side

1020mm*1000mm

Trademark

SNC

Transport Package

Customized, ESD Bag/Vacuum Packaging+Bubble Bag,

Specification

10cm*10cm

Origin

China

HS Code

8522909900

Layers

1-36 Layers



In addition, we can also produce PCBA,Impedance board & high frequency board,FPChigh frequency boardaluminum substrate circuit boardcopper based pcb ,Double sided pcb according to customer needs. We also have an automated patch production line that can do pcb assembly, and we can also make pcb copy according to the samples provided by customers.Our products will face the mid-to-high-end market, most of which can be used in medical equipment, GPS, aircraft, satellite controllers, smart cars, transmitters, etc., so we will never use cheap raw materials, nor rely on low prices to attract customers. We believe that reliable quality can win the trust and long-term cooperation of customers, and look forward to your inquiries.

Our Service
1.   PCB design ,PCB clone and copy ,ODM service.
2.   Schematic design and Layout
3.   Fast PCB&PCBA prototype and Mass Production
4.   Electronic Components Sourcing Services
5.   PCB Assembly Services:SMT,DIP&THT,BGA repair and reballing
6.   ICT, Constant Temperature Burn-in and Function Test
7.   Stencil,Cables and Enclosure building
8.   Standard Packing and On time Delivery
FAQ
Q1: How do you make sure the quality of the PCBs?
A1: Our PCBs are all 100% test including Flying Probe Test, E-test or AOI. In addition, we also have the IATF16949 certificate, which is a quality management system certification for the automotive industry. It has very high requirements for production capacity and quality. General PCB and PCBA suppliers cannot meet the application conditions.

Q2: What is the lead time?
A2: Sample needs 2-4 working days, mass production needs 7-10 working days. It depends on the files and quantity.
Q3: Can I get the best price?
A3: Yes. To help customers control cost is what we are always trying to do. Our engineers will provide the best design to save PCB material.

Q4: What files should we provide for a customized order?
A4: If only need PCBs, the Gerber files are needed; If need PCBA, both Gerber files and BOM are needed;If need PCB design,all requirement details are needed.

Q5:Can I get a free sample?
A5: Yes, Welcome to experience our service and quality.You need make the payment at first, and we will return the sample cost when your next bulk order.
