Why do we need PCBs?
To manufacture an electronic product, we usually start by designing a circuit schematic. On the schematic, various specific symbols represent different electronic components, and they are connected by wires. An electronics engineer can clearly see the circuit's working principle and the function of each part through these symbols and connections. If the circuit design is correct, you only need to prepare the necessary electronic components and connect them with wires to make it work. Early electronic products were mostly like this; if you still have a vacuum tube radio from the 1960s or 70s, you can see those messy components and crisscrossing wires.

Fortunately, the circuit of a vacuum tube radio is relatively simple, but if you want to make a more complex product, such as a computer motherboard, you can imagine what the result would be if you used the above method. It would likely require tens of thousands of wires, each one soldered individually—even the most skilled worker would be exhausted. Furthermore, this method is not suitable for mass production; therefore, we need PCBs.
